  • Dagoberto

    Date: 2025-08-05 16:30

    CR appliede to Ti (Ti 2p forum)

    Read more

    Files :

    • You must be logged-in to download data

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes

  • Dulce María

    Date: 2025-08-04 16:31

    Fitting of the Sb 3d photoemission spectrum from pure antimony using a CR II lineshape (Sb 3d forum)

    Fitting of the Sb 3d photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with a Coupled-Resonance type II lineshape. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Antimony

    • Elements: Sb

    • Sample composition: Sb

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 23.5

    • Take-off angle: 90

    Equipment and analysis software:

    • Brand: Phi

    • Model: Quantum 2000

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:37

    Fitting of the Pt 4f photoemission spectrum from metallic Platinum using a CR III lineshape (Pt 4f forum)

    Fitting of the Pt 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data


    0 votes

  • Dulce María

    Date: 2025-07-24 14:52

    Fitting of the Te 3d photoemission spectrum from pure tellurium using a CR II lineshape (Te 3d forum)

    Fitting of the Te 3d photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with a Coupled-Resonances type II lineshape, it is capable of fitting the tip of the 3d5/2 branch, unlike a CR type I or a Voigt lineshape. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat Surface

    • Sample material: tellurium

    • Elements: Te

    • Sample composition: Te

    Data acquisition parameters:

    • Photon source: Al Ka (monochromatic)

    • Pass energy: 23.5

    • Take-off angle: 90

    Equipment and analysis software:

    • Brand: PHI

    • Model: Quantum 2000

    • Software used: AAnalyzer


    0 votes

  • Dulce María

    Date: 2025-07-24 14:51

    Fitting of the Te 3d photoemission spectrum from pure tellurium using a CR I lineshape (Te 3d forum)

    Fitting of the Te 3d photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with a Coupled-Resonances type I lineshape, it is similar to a Voigt lineshape. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat Surface

    • Sample material: tellurium

    • Elements: Te

    • Sample composition: Te

    Data acquisition parameters:

    • Photon source: Al Ka (monochromatic)

    • Pass energy: 23.5

    • Take-off angle: 90

    Equipment and analysis software:

    • Brand: PHI

    • Model: Quantum 2000

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:50

    Fitting of the Bi 4f photoemission spectrum from metallic bismuth using a CR III lineshape (Bi 4f forum)

    Fitting of the Bi 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Bi

    • Elements: Bi

    • Sample composition: Bi

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 4.3

    • Take-off angle: 90

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:48

    Fitting of the Pb 4f photoemission spectrum from metallic lead using a CR III lineshape (Pb 4f forum)

    Fitting of the Pb 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Pb

    • Elements: Pb

    • Sample composition: Pb

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 4.3

    • Take-off angle: 90

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:45

    Fitting of the Tl 4f photoemission spectrum from metallic thallium using a CR III lineshape (Tl 4f forum)

    Fitting of the Tl 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Tl

    • Elements: Tl

    • Sample composition: Tl

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 4.3

    • Take-off angle: 90

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:43

    Fitting of the Hg 4f photoemission spectrum from metallic mercury using a CR III lineshape (Hg 4f forum)

    Fitting of the Hg 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Hg

    • Elements: Hg

    • Sample composition: Hg

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 4.3

    • Take-off angle: 90

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes

  • Abraham Jorge

    Date: 2025-07-24 03:40

    Fitting of the Au 4f photoemission spectrum from metallic Gold using a CR III lineshape (Au 4f forum)

    Fitting of the Au 4f photoemission spectrum for the element (research grade), data were provided by Vincent Crist (The use of the spectrum requires acknowledging XPS library website, https://xpslibrary.com/, the data is copyrighted). The main peak was fitted with two correlated Coupled-Resonances type III peak. The total background was modeled with a combination of a Tougaard type background and the interchannel coupling with valence band losses background.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Au

    • Elements: Au

    • Sample composition: Au

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 4.3

    • Take-off angle: 90

    Equipment and analysis software:

    • Software used: AAnalyzer


    0 votes
