  • Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: HfO2

    • Elements: Hf, Si, O

    • Sample composition: HfO2/HfSiO2

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 10

    Equipment and analysis software:

    • Brand: ThermoFisher Scientific

    • Model: Alpha 110

    • Software used: aanalyzer

  • Fitting of the C 1s photoemision spectrum, from a CuCO3 powder on tape. The spectrum was fitted employing four Voigt peaks. Data were provided by Vincent Crist (the use of the spectrum requieres acknowledging XPS library website, https://xpslibrary.com/).
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Powder

    • Sample material: CuCO3

    • Elements: Cu C O

    • Sample composition: CuCO3

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    Equipment and analysis software:

    • Software used: aanalyzer

  • Fitting of the C 1s photoemision spectrum, from a MgCO3 powder on tape. The spectrum was fitted employing four Voigt peaks. Data were provided by Vincent Crist (the use of the spectrum requieres acknowledging XPS library website, https://xpslibrary.com/).
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Powder

    • Sample material: MgCO3

    • Elements: Mg C O

    • Sample composition: MgCO3

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    Equipment and analysis software:

    • Software used: aanalyzer

  • Fitting of the C 1s photoemision spectrum, from a Y2(CO3)3/LaB6 sample. The spectrum was fitted employing three Voigt peaks. Data were provided by Vincent Crist (the use of the spectrum requieres acknowledging XPS library website, https://xpslibrary.com/).
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Y2(CO3)3

    • Elements: Y C O

    • Sample composition: Y2(CO3)3

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    Equipment and analysis software:

    • Software used: aanalyzer

  • XPS Neo Test

    C1s data taken from XPS Oasis and refit in XPS Neo as a test

    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat Surface

    • Sample material: Graphite

    • Elements: C, O

    • Sample composition: C

    Data acquisition parameters:

    • Photon source: Al Ka

    Equipment and analysis software:

    • Software used: XPSNeo

  • XPS Neo Test

    C1s data taken from XPS Oasis and refit in XPS Neo as a test

    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat Surface

    • Sample material: Graphite

    • Elements: C, O

    • Sample composition: C

    Data acquisition parameters:

    • Photon source: Al Ka

    Equipment and analysis software:

    • Software used: XPSNeo

  • The first peak from right to left corresponds to sp2 and the second to sp3. The other three peaks correspond to adventitious surface carbon.
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: Graphite

    • Elements: C, O

    • Sample composition: C

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Take-off angle: 90

    Equipment and analysis software:

    • Brand: Thermofisher

    • Spectrometer mode: Small area, large angle

    • Software used: aanalyzer

  • Showing HOPG C 1s spectra from different sources
    Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat Surface

    • Sample material: HOPG

    • Elements: C

    Data acquisition parameters:

    • Pass energy: 10

    Equipment and analysis software:

    • Brand: Kratos

  • Read more

    Information about the sample:

    • Shape: Powder

    • Sample material: CNT

    • Elements: C

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    Equipment and analysis software:

    • Software used: AAnalyzer

  • Read more

    Files :

    • You must be logged-in to download data

    Information about the sample:

    • Shape: Flat surface

    • Sample material: TiN

    • Elements: C

    • Sample composition: TiN

    Data acquisition parameters:

    • Photon source: Al Ka monochromatic

    • Pass energy: 10

    • Take-off angle: 85

    Equipment and analysis software:

    • Brand: Thermofisher

    • Model: Alpha110

    • Spectrometer mode: MONOXPS

    • Software used: AAnalyzer
